Max. Lamination Size 1600 × 3200 Mm Flatbed Applicator For Large-Format Signage Mounting

The MF1630-B4 Flatbed Applicator is a max sheet size flatbed applicator engineered for sign makers and wide-format graphics providers who routinely mount oversized rigid boards. Its full 1600 mm x 3200 mm working table accepts large acrylic panels, aluminum composite sheets, PVC foam boards and flexible media without the need to split jobs into smaller passes. By handling a complete board in a single operation, the machine reduces handling time, minimizes alignment errors, and protects finished graphics from damage caused by repeated repositioning.

Oversized lamination work places heavy demands on pressure distribution and positioning accuracy. Traditional roller systems struggle to keep force even across a three-meter span, which frequently leaves trapped air, edge wrinkles, or shifting media. The MF1630-B4 answers this challenge with a large-diameter silicone roller carried on a pneumatic lifting frame. The roller travels the full sheet length at a controlled, adjustable pressure so that self-adhesive vinyl, reflective film and mounting adhesive are pressed down uniformly from edge to edge.

A 15-degree tilted table improves operator ergonomics during long production runs. Operators can reach the far side of the board comfortably, and gravity assists in keeping the sheet seated against the registration guide. The LED-illuminated glass working surface reveals alignment marks and graphic edges clearly, which is essential when mounting translucent graphics, backlit displays, or double-sided signage where positioning must be exact.

Heavy steel frame construction and a reinforced aluminum table keep the work surface flat and stable over years of continuous use. The machine supports substrate thickness up to 50mm, so shops can move between thin vinyl and thick display boards without switching equipment. For print service providers that handle grand-format graphics, exhibition panels and architectural signage, the MF1632-A1 delivers the working area and stability required for repeatable, high-quality results.

• Max Lamination Size: Full 1600mm X 3200mm working area mounts oversized boards in a single pass
• Pneumatic Pressure Roller: Adjustable silicone roller distributes pressure evenly across the full sheet width
• LED Alignment Table: Backlit glass surface exposes alignment marks and graphic edges for precise registration
• Tilted Worktable: 15-degree tilt reduces operator fatigue and improves reach on large-format panels
• Thick Substrate Support: Accepts rigid boards and flexible media up to 50mm in thickness
• Heavy-Duty Frame: Reinforced steel and aluminum construction keeps the surface flat under continuous load

The MF1630-B4 Flatbed Applicator is built for grand-format signage, exhibition and trade-show graphics, architectural panels, backlit displays, traffic signage and large-format vehicle graphics. It is equally effective for mounting self-adhesive vinyl onto rigid boards and for applying protective laminating films over printed graphics. Shops processing mixed jobs of acrylic, aluminum composite and PVC foam board benefit from the ability to run all materials on a single table.

Because the full sheet is processed in one operation, the machine is particularly valuable for sign companies that must deliver flat, bubble-free, and wrinkle-free results on demanding large-format projects. The combination of stable pneumatic pressure and LED-assisted alignment makes the MF1630-B4 Flatbed Applicator a dependable core asset for high-volume signage production environments.

Each MF1630-B4 Flatbed Applicator is packed in a reinforced wooden case with foam corner protection and moisture-resistant wrapping for safe sea and land transport. Every unit undergoes full inspection and a functional pressure test before dispatch. MEFU provides a 12-month warranty, lifetime technical support and readily available spare parts, ensuring long-term reliable operation for professional production workshops.
